P550406 全流型版本

Outer Diameter	108 mm (4.25 inch)
Thread Size	M26 x 1.5
Length	135 mm (5.31 inch)
Gasket OD	73 mm (2.87 inch)
Gasket ID	56 mm (2.20 inch)
Efficiency 50%	16 micron
Efficiency Test Std	JIS D 1611
Anti-Drainback Valve	Yes
Bypass Valve	Yes
Bypass Valve Setting LR	0.5 bar (7 psi)
Bypass Valve Setting HR	0.7 bar (10 psi)
Media Type	Cellulose
Collapse Burst	6.9 bar (100 psi)
Type	Combination
Style	Spin-On
Primary Application	MITSUBISHI MD069782
