Outer Diameter 93 mm (3.66 inch)
Thread Size M22 x 1.5
Length 138 mm (5.43 inch)
Gasket OD 72 mm (2.83 inch)
Gasket ID 62 mm (2.44 inch)
Efficiency 99% 45 micron
Efficiency Test Std SAE J1858
Bypass Valve Yes
Bypass Valve Setting LR 1.2 bar (17 psi)
Bypass Valve Setting HR 1.5 bar (22 psi)
Media Type Cellulose
Collapse Burst 5.5 bar (80 psi)
Type Full-Flow
Style Spin-On
Primary Application ONAN 1220550
