Outer Diameter 101 mm (3.98 inch)
Thread Size 1-12
Length 125 mm (4.92 inch)
Gasket OD 100 mm (3.94 inch)
Gasket ID 88 mm (3.46 inch)
Efficiency 50% 20 micron
Efficiency Test Std JIS D 1611
Anti-Drainback Valve Yes
Bypass Valve Yes
Bypass Valve Setting LR 1.7 bar (25 psi)
Bypass Valve Setting HR 2.1 bar (30 psi)
Media Type Cellulose
Collapse Burst 6.9 bar (100 psi)
